High-resolution, modular, plug-and-play online printing control module designed specifically for coding applications
This product is an online printing control module designed specifically for coding applications, featuring high resolution, modular assembly, and plug-and-play functionality, which can conveniently integrate high-performance, low-maintenance thermal inkjet technology into industrial printing applications such as packaging printing and barcode printing.
Single column 600DPI
60 m/min @ 600 x 600 dpi
1 mm~54 mm printing width
7-inch high-definition display, online editing, integrated operation
Supports long-distance (5 m) transmission, suitable for various harsh operating environments
| Print Head | 0.53 inches/600dpi (Dual-row redundant design) |
| Ink Type | Water-based/Quick-drying (Water-based is suitable for absorbent materials such as paper; Quick-drying is suitable for non-absorbent materials)* |
| Ink Color | Red/Yellow/Blue/Black |
| Ink Capacity | 42 ml (depending on the selected cartridge model) |
| Maximum Printing Distance | 8 mm (depending on the selected cartridge model)* |
| Printing Width | 1 mm-54 mm (depending on the number of heads selected, a single head is 13.5 mm) |
| Printing Resolution | 600x600 dpi (maximum) |
| Printing Speed | 60 m/min @ 600x600 dpi, 120 m/min @ 300x300 dpi |
| Printable Surfaces | Cardboard/Plastic/Metal/Panels/Pipes/Stone/Cables/Electronic Components/Automotive Parts/Industrial Chemical Packaging/Pharmaceutical Food/Gift Packaging Boxes, etc. |
| Screen | 7-inch, 1024x600 capacitive touch screen |
| Data Interface | USB, Ethernet port |
| Data Memory | 4 GB |
| Control Interface | Photoelectric sensor/Synchronizer/Alarm light |
| Printing Content | Chinese, English, numbers, symbols, QR codes, barcodes, images, dates, serial numbers |
| Language | Chinese, English, Japanese (customizable) |
| Barcode Types | Barcode_128，Barcode_39，Barcode_93，EAN14，ITF14等 Description: Barcode_128, Barcode_39, Barcode_93, EAN14, ITF14, etc. |
| Data Source | Touch control screen (7-inch), USB flash drive, host computer, etc. |
| Variable Code Data Source | CSV |
| Optional Accessories | Synchronizer, Alarm light |
| Printing Temperature Setting | Supported |
| Input Voltage | AC 110~220V; 50/60 Hz |
| Operating Temperature/Humidity | 15°C~35°C/8%~80% RH |
